Index No.	Part No.	Description	Models	Obselete
1	AA0460.2CBZ	BOLT	ALL	Feb 2010
2	AA0506.1CZ	BOLT	ALL
3	AA0508.2CZB	SCREW (2)	ALL	Feb 2017
4	S1002.02A8	SCREW (2)	ALL
5	AA0714.1CZ	BOLT (2)	ALL
6	3269Y	BOLT (2)	ALL	Apr 2010
7	AA1006.10FKZB	SCREW (2)	ALL	Nov 2014
8	BA0613.2Z	WASHER (2)	ALL
9	BA0714.3Z	WASHER (2)	ALL
10	6062Y	WASHER (2)	ALL	Feb 2010
11	BA0817.2Z	WASHER	ALL	Feb 2010
12	BA0509.8Z	LOCKWASHER	ALL
13	BA1016.1WZ	LOCKWASHER (2)	ALL	Nov 2014
14	DA0400.2CZ	LOCKNUT	ALL
15	DA0600.2CZ	LOCKNUT	ALL
16	DA0700.13CZ	LOCKNUT (2)	ALL
17	DA0800.13CZ	LOCKNUT (3)	ALL
18	K0506.2A	PIN, isolator mount (2)	ALL	Nov 2014
19	K0300.2C	AXLE CARRIER (2)	ALL	Nov 2014
20	K0301.2A	STUD, axle carrier (2)	ALL	Nov 2014
21	41136-94YA	PLATE, axle adjuster (2)	ALL
22	47564-86B	REAR ISOLATOR (2)	ALL
23	FA3850.5	SEAL, swingarm (2)	ALL
24	47589-96Y	SWINGARM	ALL
25	K0500.8H	MOUNT BLOCK, swingarm	ALL	Dec 2012
26	47600-94YA	SWINGARM/DRIVE SUPPORT ASSEMBLY, w/ 47955-97Y	ALL
27	K0505.2QQ	ADJUSTING BOLT, bearing (2)	S1 1996	Feb 2010
	47685-97Y	ADJUSTING BOLT, bearing, left	S1 1997
	47743-97Y	ADJUSTING BOLT, bearing, right	S1 1997
28	47955-97Y	SPACER	ALL
29	48300-60	ROLLER BEARING, w/ cup (2)	ALL
30	48315-60	BEARING CUP (2)	ALL
31	70186-82	GROUND STRAP	ALL
32	K0200.2QQ	PIVOT SHAFT	S1 1996	Feb 2010
33	CB0049.8	WASHER (2)	ALL
34	CB0048.8	WASHER (2)	ALL	Apr 2010
35	A0520.2CZ	SCREW, M5X20 socket head (axle adjuster end plate) (2)	S1 1997	Feb 2010
36	41151-97Y	PLATE, axle adjuster (2)	S1 1997
37	B0510.1Z	WASHER, 5 mm x 10 mm (axle adjuster end plate) (2)	S1 1997	Nov 2014
38	D0508.10CZ	NUT, 5 mm, flexlock (axle adjuster end plate) (2)	S1 1997	Jan 2012
