Firebolt Models Parts Catalog
2004
AIR CLEANER - AX12
| Index No. | Part No. | Description | Models | Obselete |
|---|---|---|---|---|
| 1 | CA0012.02A8 | SCREW, shoulder (4) | XB9R | |
| 2 | HS0014.02A8 | SLEEVE | XB9R | |
| 3 | HS0016.02A8 | BREATHER HOSE, front w/ HS0014.02A8 | XB9R | |
| 4 | HS0455.02A8 | BREATHER HOSE, rear | XB9R | |
| P0138.K | SENSOR, air intake (not illustrated) (See Switches, Connectors, Sensors & Miscellaneous.) | XB9R | ||
| 5 | P0144.02A8 | SEAL, air cleaner | XB9R | |
| 6 | P0213.02A8 | FILTER ELEMENT | XB9R | |
| 7 | P0215.02A8 | COVER, air cleaner | XB9R | Nov 2014 |
| 8 | P0139.K | GROMMET | XB9R | Feb 2017 |
| 9 | P0700.02A8 | BASEPLATE ASSEMBLY, includes base plate & seal | XB9R | Nov 2014 |
| 10 | P0851.02A8 | SNORKEL, intake | XB9R | Nov 2014 |
